معرفی سوئیچ مدیریتی هوشمند D-link مدل DGS-1510-28X
DGS-1510-28X سوئیچ شبکه مدیریتی هوشمند گیگابایت با قابلیت Stack با 24 پورت +SFP و 4 پورت + Metro Ethernet SFP
| مشخصات محصول | مشخصات محصول | جزییات |
|---|---|---|
| ویژگی‌های سخت‌افزاری | لایه |
L2, L3 |
| رابط ها |
24 x 10/100/1000Mbps, 4 x 10G SFP+, Auto or configurable MDI/MDIX |
|
| 10/100/1000 Base-T Ports |
24 |
|
| PoE |
دارد |
|
| منبع تغذیه |
100 to 240 VAC, 50 to 60 Hz Internal |
|
| فن |
فن هوشمند |
|
| ابعاد(طول*عرض*ارتفاع)(میلی متر) |
440x210x44 |
|
| نشانگر LED |
Link/ Activity/Speed (per Gigabit SFP port), Link/Activity/Speed (Per 10/100/1000 Mbps port), Link/Activity/Speed (Per 10G SFP+ port), Power/Stacking ID/Fan (per device) |
|
| داخل رک |
دارد |
|
| PoE plus | PoE plus |
دارد |
| ویژگی های نرم افزاری | استانداردهای پورت |
802.3ae 10 GbE, Auto-negotiation, IEEE 802.3 10BASE-T Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3x Flow Control for Full-Duplex Mode |
| نوع سوئیچ |
مدیریتی |
|
| ظرفیت سوئیچ |
128Gbps |
|
| فایروال و امنیت دسترسی |
ARP Spoofing Prevention, BPDU Attack Protection, Broadcast/Multicast/Unknown Unicast Storm Control, D-Link Safeguard Engine, DHCP Server Screening, DHCP Snooping, DoS Attack Prevention, Dynamic ARP Inspection, IP Source Guard, IP-MAC-Port Binding, IPv6 DHCP Guard, IPv6 ND Inspection, IPv6 RA Guard, IPv6 Source Guard, Max. 64 entries, Port Security : Supports up to 128 MAC addresses per port, SSH:Supports SSH v2- Supports IPv4/v6 access, SSL:Supports v1/v2/v3 -Supports IPv4/v6 access, Traffic Segmentation |
|
| مدیریت |
SmartConsole Utility, SNMP, System Log, Telnet Server, TFTP Client, Trap for SmartConsole Utility, BootP/DHCP Client, Command Line Interface (CLI), Compact CLI through Telnet, Configurable MDI/MDIX, D-Link Network Assistant support1, Debug command, DHCP Auto Configuration, DHCP Relay, Dual Images, IPv6 Neighbor Discovery, Max. 10,000 log entries, NTP, SNMP Trap, Supports IPv4 log server, Supports v1/v2/v3, Surveillance mode2, Telnet client (supports CLI only), Web-based GUI |
|
| VLAN |
4K VLAN Groups, 802.1Q tagged VLAN VLAN Group, Auto Surveillance VLAN 2.02, GVRP, MAC-based VLAN, Max. 256 static VLAN groups, Max. 4094 VIDs Management VLAN Asymmetric VLAN Auto Voice VLAN, Protocol-based VLAN |
|
| عملکردهای لایه 3 |
16 IP interfaces, 256 Static ARP, 32 IPv6 Static Route Entries, Default Route, IPv6 Neighbor Discovery (ND), Max. 64 IPv4 entries, Static Route, Supports Gratuitous ARP, UDP Helper |
|
| کیفیت خدمات (QOS) | Number of Queues per port |
8 |
| Priority Queue Mapping based on DSCP |
دارد |
|
| Weighted Round Robin (WRR) |
دارد |
|
| عملکرد | MAC-address table |
16K |
| عملکردهای لایه 2 |
802.1D STP, 802.1w RSTP Loopback Detection 802.3ad Link Aggregation, 802.3ad Link Aggregation, 802.3x Flow Control, ERPS (Ethernet Ring Protection Switching), Filters all unregistered groups Spanning Tree Protocol, Flow Control, Forwards all unregistered groups, HOL Blocking Prevention, HOL Blocking Prevention IGMP Snooping, Host-based MLD Fast Leave, IGMP per VLAN, IGMP v1/v2 Snooping, Jumbo Frames up to 9216 Byte, LLDP, LLDP-MED, Loopback Detection, Many-to-One, Max. 32 groups per device/8 ports per group, MLD Snooping, Multicast Filtering, One-to-One, Per VLAN IGMP snooping, Per VLAN MLD Snooping, Port Mirroring Support 4 mirroring groups, Spanning Tree (STP, RSTP, MSTP), Supports 128 Static Multicast Addresses, Supports 256 IGMP snooping groups, Supports 512 groups, Supports 64 static multicast addresses, Supports IGMP Querier L2 Multicast Filtering, Supports Mirroring for Tx/Rx/Both Cable Diagnostics Configurable MDI/MDIX, Supports MLD v1/v2 awareness |
|
| سایر ویژگی‌ها | گواهی نامه ها |
BSMI, C-Tick, CB, CCC, CE, cul, FCC, VCCI |
| پشتیبانی از D-LINK Green |
دارد |
|
| گارانتی | گارانتی |
2 سال گارانتی ایزی |
